Grout Pumps & Associated Equipment

Grout pumps play a crucial role in the construction industry, particularly in the process of post-tensioning, which is a method used to reinforce concrete.

These specialized pumps are designed to efficiently inject grout - a mixture of water, cement, and grout - into ducts within concrete structures where steel tendons are housed.

The grout serves multiple purposes: it protects the steel tendons from corrosion, provides bonding between the concrete and tendons, and fills any voids to ensure structural integrity. Small selection stated below:

Jack Code	Descriptions	Pressure SWL (Bar)	Selection Range
FJ-INJECT	Injection and Resin System	20-200 Bar	0.5 - 150 litres Grout/Resin Reservoir
GP-HAND	Grout Hand Pump - 35 litres reservoir	0-15 Bar	Diapghram Pump
GP-50	Grout Hand Pump - 50 litres reservoir	0-20 Bar	c/w Internal Mixers
GP-DES	Electric 110V/220V Screw Grout-Pump	0-20 Bar	Flow / Speed Control (0-13.5 l/min)
GP-600	Electric Grout Pump - 110V (32 Amps)	0-11 Bar	35 litres Reserv. Tank 2-10 litres per/min
GP-MK3	Electric Grout Pump MK3 - 110V (32 Amps)	0-11 Bar	70 litres Reserv. Tank 2-30 litres per/min
Note:	We have the facility to manufacture bespoke hoses, grout pumps, injection system and control panels to suit all grouting requirements

Jack Code	Descriptions	Pressure SWL (Bar)	Selection Range
PT-554	Hydraulic High-Flow Stressing Pump (110-220V) c/w Control Block and Valve	700	Pressure Control Relief Valve
PT-ONION	Hydraulic Onion Jack - 10 tonnes (100 kNs)	700	12.7mm to 15.2mm
PT-SEAT	Hydraulic Analogue, Force and Digital Pressure Gauge	1 - 1600	60mm to 200mm Dia.
PT-STRAND	Strand Wire/Cable Pusher - 110V and 220V	110V / 220V	12.7mm to 15.2mm
PT-DISP	Strand Dispenser - for Post-Tensioning	500 Kgs SWL	Lifting Eyes, Nose Cone and Safety Lid (on request)
PT-GPUMP	Manual Hand & Electric Grout Pumps - for duct voids	-	12.7mm to 15.2mm
PT-SJWEDGE	Post-Tensioning Wedge (one-use and reusable)	-	12.7mm to 18mm
PT-OJWEDGE	Post-Tensioning Onion Wedge (reusable)	-	12.7mm to 15.2mm

Jack Code	Descriptions	Type	Pressure SWL (Bar)	Selection Range
PT/HH-XX	Grout Pump Hose	24mm - 110mm	5 - 150 Bar	All options/lengths on request
PT-FIT-XX	Grout Pumps Hose Adaptor, Valves and Fittings	1/4", 3/8" + 1/2"	5 - 150 Bar	Various Fittings
GPG-XX	Grout Pressure Gauge	1/4", 3/8" + 1/2"	12 Bar	60mm to 200mm Dia.
PT-GFIT	Grout Fittings - Elbows, Straight and Adaptors	All types	5 - 150 Bar	All options available on request
PT-CHAIRS-X	Post-Tensioning Duct Chairs	43, 46.5, 70 and 86mm wide duct	-	Height and colour options: 25 - 430mm
PT-FORM-XX	Void Formers / Polyformers	2-5 strand	-	Anchors Formers for all Types
PT-TUBE-XX	Grout Tubes and Connectors	12mm, 19mm to 1/4", 3/8" + 1/2"	5 - 150 Bar	Anchors Formers for all Types
PT-STRAND-X PT-BAR-XX	Post Tensioning Strand Wire / Stressing-Cable Post-Tension and Stressing Bar	5mm to 18mm 16mm - 130mm	-	Offering strand wire, cable, dywidag and macalloy to all systems
